| 型号名称 |
能力 螺丝 直径 (参考) mm |
转矩范围N.m | 无负荷回转速度(约)rpm |
全长 无套筒 (约)mm |
重量 无套筒 (约)kg |
从轴心 到侧面 (约)mm |
刀头 插入 尺寸 mm |
软管 接头 螺纹 |
推荐 软管 内径 mm |
空气 耗气量 |
噪音值 dB(A) |
振动 加速度 (3-axes) m/S2 |
产品 代码 |
||||
| 0.4MPa | 0.5MPa | 0.6MPa | 0.4MPa | 0.5MPa | 0.6MPa | ||||||||||||
| ALPHA-50MC | 6 | 5.0-10.0 | 6.5-12.0 | 7.5-15.0 | 5100 | 5500 | 5700 | 191 | 1.25 | 25.5 | 9.5Sq | RC¼ | 6.35 | 0.20 | 75 | 2.5未满 | 14871 |
| ALPHA-60MC | 6 | 8.0-13.0 | 9.0-15.0 | 10.0-20.0 | 6500 | 6800 | 7000 | 215 | 1.40 | 25.5 | 9.5Sq | RC¼ | 9.5 | 0.25 | 75 | 2.5未满 | 14921 |
| ALPHA-70MC | 8 | 11.0-22.0 | 12.5-25.0 | 15.0-30.0 | 6500 | 6800 | 7300 | 215 | 1.43 | 25.5 | 9.5Sq | RC¼ | 9.5 | 0.25 | 75 | 2.5未满 | 14891 |
| ALPHA-80MC | 8 | 12.0-25.0 | 16.0-30.0 | 20.0-40.0 | 6500 | 6800 | 7000 | 231 | 1.50 | 25.5 | 9.5Sq | RC¼ | 9.5 | 0.45 | 78 | 2.5未满 | 14941 |
| ALPHA-90MC | 8-10 | 17.5-35.0 | 20.0-40.0 | 30.0-47.0 | 5200 | 6000 | 6500 | 231 | 1.50 | 25.5 | 9.5Sq | RC¼ | 9.5 | 0.45 | 78 | 2.5未满 | 14901 |
| ALPHA-101MC | 10 | 30.0-50.0 | 34.0-58.0 | 38.0-70.0 | 5700 | 6000 | 6200 | 243 | 2.10 | 28.0 | 12.7Sq | RC¼ | 9.5 | 0.50 | 80 | 2.5未满 | 14981 |
| ALPHA-110MC | 12 | 35.0-60.0 | 45.0-75.0 | 55.0-100.0 | 4000 | 4500 | 5000 | 250 | 2.50 | 30.0 | 12.7Sq | RC¼ | 9.5 | 0.65 | 80 | 2.5未满 | 14961 |
| ALPHA-130MC | 14 | 70.0-115.0 | 80.0-130.0 | 90.0-150.0 | 3000 | 3200 | 3400 | 276 | 3.50 | 36.0 | 12.7Sq | RC¼ | 9.5 | 0.65 | 82 | 2.5未满 | 14971 |
| ALPHA-140MC | 16 | 120.0-180.0 | 140.0-200.0 | 150.0-220.0 | 3100 | 3300 | 3500 | 295 | 4.63 | 40.0 | 19.0Sq | RC¼ | 9.5 | 0.80 | 84.5 | 2.8 | 14991 |
| UXR-1820MC | 18 | 120.0-200.0 | 140.0-220.0 | 160.0-250.0 | 4000 | 4400 | 4600 | 322 | 5.50 | 42.0 | 19.0Sq | RC⅜ | 12.7 | 0.70 | 84 | 2.5未满 | 14851 |
| UXR-2000MC | 20 | 150.0-300.0 | 200.0-350.0 | 250.0-400.0 | 4300 | 4600 | 4800 | 355 | 8.00 | 47.0 | 19.0Sq | RC⅜ | 12.7 | 0.95 | 85 | 2.7 | 14861 |
| ALPHA-60SMC | 6 | 8.0-13.0 | 9.0-15.0 | 10.0-17.0 | 5700 | 6000 | 6300 | 280 | 1.40 | 25.5 | 9.0Sq | RC¼ | 9.5 | 0.25 | 75 | 2.5未满 | 14651 |
| UXR-2400SMC(OUT) | 24 | 250.0-500.0 | 300.0-550.0 | 350.0-600.0 | 3000 | 3100 | 3300 | 457 | 12.50 | 55.0 | 25.4Sq | RC½ | 12.7 | 1.00 | 85 | 3.8 | 16601 |
| ALPHA-50DMC | 6 | 5.0-10.0 | 6.5-12.0 | 7.5-15.0 | 5100 | 5500 | 5700 | 191 | 1.25 | 25.5 | 6.35Hex | RC¼ | 6.35 | 0.20 | 75 | 2.5未满 | 14881 |
| ALPHA-60DMC | 6 | 8.0-13.0 | 9.0-15.0 | 10.0-20.0 | 6500 | 6800 | 7000 | 215 | 1.40 | 25.5 | 6.35Hex | RC¼ | 9.5 | 0.25 | 75 | 2.5未满 | 14931 |
