| 型号名称 |
能力螺丝直径 (参考)mm |
转矩范围 N·m |
无负荷运转速度 (约)rpm |
全长无套筒/刀头 (约)mm |
重量无套筒/刀头 (约)kg |
从轴心到侧面 (约)mm |
套筒/刀头插入尺寸 mm |
噪声值 db(A) |
产品代码 |
| UEP-50 | 5 | 5.0-10.0 | 2000 | 165.5 | 1.80 | 28.0 | 9.5Sq | 59.0 | 13651 |
| UEP-60 | 6 | 10.0-25.0 | 2000 | 188.0 | 2.05 | 28.0 | 9.5Sq | 68.0 | 13671 |
| UEP-70 | 8 | 25.0-40.0 | 2000 | 203.5 | 2.30 | 31.0 | 9.5Sq | 73.0 | 13691 |
| UEP-80 | 8-10 | 30.0-60.0 | 2000 | 202.0 | 2.73 | 36.5 | 12.7Sq | 71.0 | 13701 |
| UEP-100 | 10-12 | 60.0-120.0 | 2000 | 233.5 | 3.66 | 36.5 | 12.7Sq | 75.0 | 13711 |
| UEP-50D | 5 | 5.0-10.0 | 2000 | 170.5 | 1.80 | 28.0 | 6.35Hex | 59.0 | 13661 |
| UEP-60D | 6 | 10.0-25.0 | 2000 | 193.0 | 2.05 | 28.0 | 6.35Hex | 68.0 | 13681 |
