| 型号 | 能力螺丝直径mm | 无负荷空转速度rpm | 全长(不包括套筒或者刀头)mm | 重量(不包括套筒或者刀头)kg | 轴心到侧面距离mm | 套筒插入尺寸mm | 软管接头螺纹 | 推荐的软管内径mm | 空气耗气量m3/min | 噪声值dB(A) | 产品代码 |
| UW-6SSLRK | 6 | 8500 | 239 | 0.87 | 31.0 | 9.5Sq | RC¼ | 9.5 | 0.30 | 90 | 00671 |
| UW-6SSRK | 6 | 7500 | 225 | 0.97 | 29.5 | 9.5Sq | RC¼ | 9.5 | 0.30 | 90 | 01271 |
| UW-6SSHRK | 8 | 7300 | 249 | 1.26 | 27.5 | 9.5Sq | RC¼ | 9.5 | 0.35 | 91 | 01971 |
| UW-6SSLK | 6 | 8500 | 197 | 0.87 | 31.0 | 9.5Sq | RC¼ | 9.5 | 0.30 | 91 | 00631 |
| UW-6SSK | 6 | 7500 | 185 | 0.97 | 28.0 | 9.5Sq | RC¼ | 9.5 | 0.30 | 91 | 01231 |
| UW-6SSHK | 8 | 7500 | 205 | 1.21 | 27.5 | 9.5Sq | RC¼ | 9.5 | 0.35 | 92 | 01931 |
| UW-6SSLRDK | 6 | 8500 | 245 | 0.87 | 31.0 | 6.35Hex | RC¼ | 9.5 | 0.30 | 90 | 00771 |
| UW-6SSRDK | 6 | 7500 | 241 | 0.97 | 29.5 | 6.35Hex | RC¼ | 9.5 | 0.30 | 90 | 01371 |
| UW-6SSHRDK | 8 | 7300 | 265 | 1.26 | 27.5 | 6.35Hex | RC¼ | 9.5 | 0.35 | 91 | 01991 |
| UW-6SSLDK | 6 | 8500 | 203 | 0.90 | 31.0 | 6.35Hex | RC¼ | 9.5 | 0.30 | 91 | 00731 |
| UW-6SSDK | 6 | 7500 | 202 | 1.00 | 28.0 | 6.35Hex | RC¼ | 9.5 | 0.30 | 91 | 01331 |
| UW-6SSHDK | 8 | 7500 | 220 | 1.25 | 27.5 | 6.35Hex | RC¼ | 9.5 | 0.35 | 92 | 14631 |
| UW-6SSHDK | 6 | 8000 | 258 | 1.17 | 31.0 | 9.5Sq | RC¼ | 9.5 | 0.30 | 93 | 00871 |
| UW-6CSRK | 6 | 7300 | 257 | 1.42 | 29.5 | 9.5Sq | RC¼ | 9.5 | 0.30 | 94 | 01471 |
| UW-6CSHRK | 8 | 6300 | 282 | 1.71 | 27.5 | 9.5Sq | RC¼ | 9.5 | 0.30 | 94 | 02071 |
| UW-6ASLRK | 6 | 6500 | 277 | 1.14 | 31.0 | 9.5Sq | RC¼ | 9.5 | 0.30 | 92 | 00971 |
| UW-6CSLK | 6 | 8000 | 217 | 1.17 | 31.0 | 9.5Sq | RC¼ | 9.5 | 0.30 | 93 | 00831 |
| UW-6CSK | 6 | 7500 | 218 | 1.42 | 28.0 | 9.5Sq | RC¼ | 9.5 | 0.30 | 94 | 01431 |
| UW-6CSHK | 8 | 7500 | 238 | 1.71 | 27.5 | 9.5Sq | RC¼ | 9.5 | 0.35 | 94 | 02031 |
| UW-6ASLK | 6 | 6500 | 235 | 1.14 | 31.0 | 9.5Sq | RC¼ | 9.5 | 0.30 | 92 | 00931 |
